AMU – Automatic Magnet Unit
Built for Scientists, by Scientists
Whether you need high-throughput DNA extraction or precise RNA clean-up, the AMU delivers reliable, reproducible results with ease.
Description
AMU – Automatic Magnet Unit
At Ariumlab, we’ve combined our deep expertise in magnetic bead extraction with cutting-edge automation to bring you the AMU – Automatic Magnet Unit.
This unique solution streamlines magnetic bead purification across a wide range of molecular biology and proteomics workflows. The AMU features high-performance magnets for rapid and efficient bead collection with minimal loss or carryover. The magnet height is fully adjustable, enabling precise control over separation based on your sample volume and protocol requirements.
Designed for maximum versatility, AMU – Automatic Magnet Unit can be:
- Seamlessly integrated with automated pipetting platforms for semi or fully automated workflows
- Or used as a standalone unit for manual applications
Thanks to its interchangeable adapters, the AMU – Automatic Magnet Unit supports up to 5 different plate types and tube formats, allowing you to process various sample types in parallel — boosting throughput and efficiency.
And best of all: the AMU – Automatic Magnet Unit delivers walk-away automation without the need for costly robotic arms or grippers — making high-quality magnetic bead purification more accessible than ever.
APPLICATIONS
PCR Clean-Up
Efficient purification of PCR products using magnetic beads to remove unwanted primers, nucleotides, and enzymes.
NGS Library Clean-Up
Streamlined single or dual-size selection steps in NGS library prep workflows using magnetic bead-based separation.
Nucleic Acid Extraction
Rapid and reliable isolation of high-quality DNA or RNA from various sample types using magnetic bead technology.
Protein Enrichment
Selective concentration and purification of target proteins from complex biological samples via magnetic bead capture.
Why Choose AMU – Automatic Magnet Unit?
Magnet plates remain fully disengaged in the lower position, preventing unwanted bead capture during setup or pipetting.
No mounting or locking mechanisms. Just place your plate and run your protocol — it’s that easy.
Easily swap and configure magnet plates to suit different well shapes, plate types, and applications.
Flexible and future-proof — compatible with a wide range of standard labware.
Works effortlessly with both 1.5 mL and 2 mL tubes, supporting broader workflows.
Engineered for smooth interaction with robotic grippers — or operate without them for even simpler setups.
Powered by USB, eliminating bulky external power supplies. Ideal for mobile platforms and tight spaces.*USB output should support 10W or more.
Whether you need high-throughput DNA extraction or precise RNA clean-up, the AMU delivers reliable, reproducible results with ease.
We offer custom magnet plate designs tailored to your specific plates and workflows.
Let the AMU Magnetic Module transform your lab — from manual prep to hands-free purification.
👉 Contact us to request a demo, integration guidance, or a quote.
The Most Compact Magnetic Module on the Market
AMU’s space-saving footprint makes it ideal for busy labs and compact robotic decks — all without compromising power or functionality.
Specifications – Temperature
| Operating Conditions | Temperature: 5 to 40 °C — Humidity: <80 % |
| Power Requirements | 100-240 VAC, 50/60Hz, Device input: 12V, 24 Watt |
| Dimensions | 127.6mm (L) x 85.6mm (W) x 69mm (H) |
| Weight | 1.5kg (3.1Ibs) |
| Order No | Name | Description |
|---|---|---|
| D001-A00M-0015 | AMU 4×6 1.5mL Adapter | Adapter for 1.5 ml tubes, 4 x 6 format |
| D001-A00M-0096 | AMU PCR Adapter | Adapter for 96 well PCR plate |
| D001-A00M-00LB | AMU LoBind Adapter | Adapter for kingfisherl deep well plate |
| D001-A00M-00KF | AMU KF Adapter | 1.5kg (3.1Ibs) |
| D001-A00M-00AD | AMU 96 Well Adapter | Adepter for PCR microplates including deep well, flat bottom, pyramid bottom, round bottom and full-skirt PCR plates |
Adapter for 1.5mL Tubes
Adapter for LoBind Plates 96 DeepWell Plates Tubes
Adapter for 96 Well PCR Plates
